Mondraker Crafty R 2024

£5,699.00 VAT included

SKU: N/A Categories: , , Tags: , , ,

For long days riding over demanding terrains and big features, Mondraker present the Crafty electric mountain bike. All that Mondraker frame design expertise boosted with the rider favourite Bosch Smart power unit makes for an E-MTB ready for everything the Earth has to offer. The aluminium frame shares the exact same geometry as the carbon, though makes these amazing bikes available at a lower price point.

The Crafty R rocks Mondraker’s ZERO suspension system kinematics which provides a super supple suspension action while at the same time not wasting any energy in the process. What’s more, the bike’s really agile on the trail which is much-needed in an E-MTB. It all adds up to maximum fun and excellent value for money. It comes complete with Bosch’s Performance CX Line Smart Control motor, the all-new Mini Remote control and integrated System Controller. The Crafty R is without doubt one of the most competitive enduro e-bikes out there.

Bosch Smart System –

The latest Bosch motor is a Performance Line CX GEN4 unit that pushes out 85nm, featuring the new Bosch Smart System, upgraded software and enhanced firmware modifications. In addition, a new display unit and handlebar mounted control module have been added for easier mode selection and adjustment. The bikes also feature the new Bosch 750Wh battery that allows you to enjoy even more kilometers of trail on a single charge.


  • S: 160cm – 170cm
  • M: 165cm – 180cm
  • L: 175cm – 185cm
  • XL: 185cm – 190cm+


  • MATERIAL Stealth Alloy
  • REAR TRAVEL150mm
  • WARRANTYLifetime (frame)

Frame – Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
Rear shock – Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
Shock settings – medium compression, medium rebound, air volume spacer 0.2
Fork – Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
Headset – Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41×30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Stem – Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar – Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips – Onoff Desert, 1lock-on, 135mm
Seatpost – Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405×95-125mm, M size: 458×120-150mm, L size: 498×140-170mm, XL size: 558×170-200mm
Saddle – FIZIK Terra Aidon X5 145mm
Front brake – Sram DB8, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear brake – Sram DB8, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Brake lever – Sram DB8, tool reach adjust, lever pivot bushings
Rims – Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes – Mavic J-bend double butted, contactless lacing
Front hub – Mavic, Boost 15x110mm, IS 6 bolts
Rear hub – Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire – Maxxis Minion DHF 29×2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Rear tire – Maxxis Minion DHR II 29×2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
Crankset – Race Face Aeffect ebike, 165mm
Rings – Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain – Sram SX Eagle, 12s, Powerlock
Rear derailleur – Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers – Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
Cassette – Sram PG-1210, 11-50T, 12s
Derailleur hanger – Mondraker M068
Weight – 25,9 kg
Display – Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller
Motor – Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM
Battery – Bosch Powertube 750Wh

Frame Size

Extra Large, Large, Medium, Small
