Large now in stock, Sml and Extra Large available to order. Medium already sold out
Very limited stock coming to the UK.
Designed to go where no normal fat bike can, the Surly Moonlander is for riders who want otherworldly capabilities on rocky shorelines, sand, snow, and desolate landscapes not yet discovered. While our proprietary 24 x 6.25" tires surpass the limitations of current fat bikes, the Moonlander still rides like a normal bike, making it easier (and more fun) to navigate previously unrideable terrain. It’s the ultimate choice for explorers who itch for the next great adventure, and aren’t afraid of what they might find.
Frame
Surly Moonlander Frame - 100% Surly Chromoly steel. E.D. coated. Triple-butted main triangle. TIG-welded.
Fork
Surly Moonlander Fork - 100% Surly Chromoly steel. 1-1/8" straight steerer with tapered straight blade, TIG-welded, E.D. Coated. 51mm IS front standard disc mount. 197mm x 12mm thru-axle dropouts (axle included).
Color
Lunar Dust Gray
Front Derailleur
N/A
Rear Derailleur
9-speed Pinion gearbox
Cassette
34t aluminum ring
Chain
KMC EPT
Crankset
Pinion for Surly crankset, with Pinion high-offset spider, 32t
Shifter
Pinion twist
Brakes and Rotors
Tektro HD M-285, Tektro, 180mm, 6-bolt
Headset
Cane Creek 40
Stem
Promax, 31.8, 4-bolt
Handlebar
Surly Terminal
Grips / Bar Tape
Velo Lock-on
Seatpost
TransX YSP15JL Dropper, 125mm travel (100mm travel on SM)
Saddle
WTB Volt
Front Hub
197x12mm, Novatec, 32h, Thru-Axle
Rear Hub
197x12mm, Novatec, 32h, Thru-Axle
Rims
Surly Clown Royal 24", 100mm wide
Tires
Surly Molenda 24 x 6.2", TBD tpi, folding wire bead

| Frame measurements (mm) | SM | MD | LG | XL |
|---|---|---|---|---|
| A. Effective Top Tube | 575 | 605 | 635 | 665 |
| B. Stand Over | 736 | 769 | 793 | 801 |
| C. Reach | 398 | 420 | 444 | 468 |
| D. Stack | 578 | 606 | 625 | 644 |
| E. Total Seat Tube Length | 368 | 419 | 480 | 521 |
| F. Headtube Length | 120 | 150 | 170 | 190 |
| G. Headtube Angle | 68.5 | 68.5 | 68.5 | 68.5 |
| H. Seat Tube Angle | 73 | 73 | 73 | 73 |
| I. BB Drop | 45 | 45 | 45 | 45 |
| J. BB Height | 394 | 394 | 394 | 394 |
| K. Chainstay Length | 562 | 562 | 562 | 562 |
| L. Fork Length Axle to Crown | 460 | 460 | 460 | 460 |
| M. Fork Offset | 50 | 50 | 50 | 50 |
| N. Wheelbase | 1215 | 1248 | 1280 | 1311 |
| Component measurements (mm) | ||||
| Crank Arm Length | 170 | 170 | 170 | 170 |
| Handlebar Width | 735 | 735 | 735 | 735 |
| Stem Length | 60 | 60 | 70 | 80 |
